Akyga
EMI Suppression Filter EN2060-20-F 20A
17.780 Ft
gross price
Supplier stock · approx. 1-2 weeks
Item number: EN2060-20-F
- ✓ 24-month warranty
- ✓ Fast delivery nationwide
- ✓ 14-day right of withdrawal
Notify me (stock or price drop)
Specifications
| Product code | EN2060-20-F |
| Product type | EMI filter |
| Filter type | Anti-interference |
| Maximum operating current | 20 A |
| Connectors | 6,3 mm priključci |
| Leakage current | 0.43mA @120 VAC 60 Hz, 0.74mA @250 VAC 50 Hz |
| Number of poles | 2 |
| Material | Metal |
| Temperature | -25`C - +100`C |
| Product size (L x W x H) | 115 x 57 x 45 mm |
| CE compliance | Yes |
| RoHS compliance | Yes |
| REACH compliance | Yes |
| EAN code | 5901720138750 |
0 more technical details
The data shown comes from the manufacturer; illustrations may differ.
Description
The EN2060-20-F EMI filter is a reliable solution for applications where protection against higher current electromagnetic interference is crucial. Supporting up to 20 A, it is ideal for demanding power systems – both in industrial environments and advanced electronic equipment.
Thanks to its 6.3 mm connectors, the filter's installation is quick and intuitive, and its robust metal casing guarantees durability and effective suppression of external interference. With its low leakage current and wide operating voltage range, the EN2060-20-F interference filter combines high performance with operational safety – ensuring a clean, stable power supply in all situations.
