Power Supply AK-EV-03 42V / 2A 84W Cannon XLR Male
- ✓ 24-month warranty
- ✓ Fast delivery nationwide
- ✓ 14-day right of withdrawal
Notify me (stock or price drop)
Specifications
| Product code | AK-EV-03 |
| Responsible organisation | Akyga Europe Sp. z o.o., 52-200 Suchy Dwór, Wrocławska 1c, Polska/Poland, contact@akyga.com |
| Product type | AC/DC adapter |
| Supply voltage | 100-240 V |
| Power consumption | < 2.5 A |
| Efficiency | > 80 % |
| Output voltage | 42.0 V |
| Output current | 2 A |
| Output cable length | 1 m |
| Output connector | Cannon (3 DIN) XLR (m) |
| Maximum power | 84 W |
| Power input | IEC C8 |
| Mechanical switch | None |
| Grounding | None (class II) |
22 more technical details
| IP rating | IP20 |
| OVP | Yes |
| OCP | Yes |
| OPP | Yes |
| SCP | Yes |
| With ferrite filter | None |
| Power cable included | None |
| Material | ABS |
| Product colour | Black |
| Backlight colour | Bicolor LED |
| Display | None |
| MTBF | 10000 h |
| Packaging | EcoBox |
| Product size (L x W x H) | 140 x 59 x 33 mm |
| Package size (L x W x H) | 190 x 92 x 38 mm |
| Net weight | 322 g |
| Gross weight | 371 g |
| CE compliance | Yes |
| RoHS compliance | Yes |
| REACH compliance | Yes |
| EAN code | 5901720135902 |
| Warranty | 24 months |
Description
The Akyga® AK-EV-03 is a product designed for bicycle and electric scooter chargers. The device is equipped with the popular IEC C8 socket. The output cable of the charger (1 m long) is terminated with a Cannon XLR plug, which is characterized by high resistance to mechanical damage. With an output of 42 V / 2 A, the product has a maximum power of 84 W. The device is designed to charge scooters and eBikes equipped with 36 V batteries. The charger's high efficiency exceeds 80%. It is also equipped with an LED controller that indicates the duration or completion of the charging process. Available in black, in environmentally friendly Ecobox packaging.
The power supply is compatible with bicycle brands such as Haibike, Merida, Batavus, Ecobike, Giant, Fischer, Freway, Gazelle, etc.
