Power supply AK-EV-09 54.6V / 2A 110W without termination
- ✓ 24-month warranty
- ✓ Fast delivery nationwide
- ✓ 14-day right of withdrawal
Notify me (stock or price drop)
Specifications
| Product code | AK-EV-09 |
| Responsible organisation | Akyga Europe Sp. z o.o., 52-200 Suchy Dwór, Wrocławska 1c, Polska/Poland, contact@akyga.com |
| Product type | AC/DC adapter |
| Supply voltage | 100-240 V |
| Power consumption | < 2.5 A |
| Efficiency | > 80 % |
| Output voltage | 54.6 V |
| Output current | 2 A |
| Output cable length | 1 m |
| Output connector | Unsealed |
| Maximum power | 110 W |
| Power input | IEC C8 |
| Mechanical switch | None |
| Grounding | None (class II) |
22 more technical details
| IP rating | IP20 |
| OVP | Yes |
| OCP | Yes |
| OPP | Yes |
| SCP | Yes |
| With ferrite filter | None |
| Power cable included | None |
| Material | ABS |
| Product colour | Black |
| Backlight colour | Bicolor LED |
| Display | None |
| MTBF | 10000 h |
| Packaging | EcoBox |
| Product size (L x W x H) | 172 x 73 x 37 mm |
| Package size (L x W x H) | 190 x 92 x 38 mm |
| Net weight | 215 g |
| Gross weight | 264 g |
| CE compliance | Yes |
| RoHS compliance | Yes |
| REACH compliance | Yes |
| EAN code | 5901720136077 |
| Warranty | 24 months |
Description
The Akyga® AK-EV-09 is a power supply for charging electric vehicles with a 48 V (13s) battery. The product does not have a connector at the end of the output cable, which allows any connector to be attached to the device. The 1-meter cable allows comfortable charging of an e-bike or electric scooter. What is more, the device is adapted to be powered by a cable with an IEC C8 connector, commonly used in power supplies. A significant advantage of the charger is its high efficiency, exceeding 80%. It is equipped with an LED light indicating the duration or completion of the charging process. The product is available in black, in environmentally friendly Ecobox packaging.
Warning! Power supplies are intended only for people with proper qualifications. Improper use may result in a fatal electric shock.
